ASUS PRIME H410M-K (LGA 1200) mic-ATX Motherboard:

Specifications of ASUS PRIME H410M-K

• CPU
  Intel® Socket 1200 for 10^th Gen Intel^® Core^™, Pentium^® Gold and Celeron^® Processors *
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
  * Refer to www.asus.com for CPU support list
  **Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
• Chipset
  Intel® H410
• Memory
  2 x DIMM, Max. 64GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
  Dual Channel Memory Architecture
  Supports Intel® Extreme Memory Profile (XMP)
  OptiMem
  * 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• Graphic
  Integrated Graphics Processor
  1 x DVI-D
  1 x D-Sub
  *Graphics specifications may vary between CPU types.
• Expansion Slots
  Intel® 10th Gen Processors
  1 x PCIe 3.0 x16 (x16 mode)
  Intel® H410 Chipset
  2 x PCIe 3.0 x1
• Storage
  Total supports 4x SATA 6Gb/s ports
  Intel® H410 Chipset :
  4 x SATA 6Gb/s port(s)
• LAN
  Realtek® RTL8111H
• Audio
  Realtek ALC887 7.1-Channel High Definition Audio CODEC *
  – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
  Audio Feature :
  – Audio Shielding
  – Dedicated audio PCB layers
  * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
• USB Ports
  Rear USB Port ( Total 6 )
  2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
  4 x USB 2.0 port(s)(2 x Type-A)
  Front USB Port ( Total 4 )
  2 x USB 3.2 Gen 1 port(s)
  2 x USB 2.0 port(s)
• Software Features
  ASUS Exclusive Software
  Armoury Crate
  AI Suite 3
  – Performance And Power Saving Utility
  TurboV EVO
  EPU
  Digi+ VRM
  Fan Xpert
  – EZ update
  ASUS CPU-Z
  AI Charger
  DAEMON Tools
  Norton Anti-virus software (Free Trial for 60 days)
  WinRAR
  UEFI BIOS
  ASUS EZ DIY
  – ASUS Crash Free BIOS 3
  – ASUS EZ Flash 3
  – ASUS UEFI BIOS EZ Mode
• ASUS Special Features
  ASUS 5X PROTECTION III
  – ASUS DIGI+ VRM
  – ASUS LAN Guard
  – ASUS Overvoltage Protection
  – ASUS Safe Slot Core
  – ASUS Stainless-Steel Back I/O
  ASUS Q-Design
  – ASUS Q-DIMM
  – ASUS Q-Slot
  ASUS Thermal Solution
  – Aluminum heat sink design
• Back I/O Ports
  1 x PS/2 keyboard (purple)
  1 x PS/2 mouse (green)
  1 x DVI-D
  1 x D-Sub
  1 x LAN (RJ45) port(s)
  2 x USB 3.2 Gen 1 Type-A
  4 x USB 2.0
  3 x Audio jack(s)
• Internal I/O Ports
  1 x CPU Fan connector(s)
  1 x Chassis Fan connector(s)
  1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
  1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
  4 x SATA 6Gb/s connector(s)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin EATX 12V Power connectors
  1 x Front panel audio connector(s) (AAFP)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
  1 x COM port header
  1 x Speaker connector
• Accessories
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x Supporting DVD
  User manual
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS
• Manageability
  WOL by PME, PXE
• Operating System
  Windows® 10 64-bit
• Form Factor
  mATX Form Factor
  8.9 inch x 7.9 inch ( 22.6 cm x 20.3 cm )
